Yellow Overdoor Light and sounder Stainless steel

£62.84 Ex Vat
In stock
Product code
S1778SY
Yellow Overdoor Light and sounder Stainless steel

Stainless Steel flush fitting overdoor light and sounder with 16mm Yellow Jumbo LED. There are separate terminals provided for the LED. The LED and sounder current limit resistor is provided for 12 vdc operation.

Specification:
  • Led Current - 50mA@12vdc
  • Switch Contacts - N/A
  • Sounder Current - 40mA @ 12vdc
  • Visual Indication - 1 x Yellow jumbo LEDs
  • Integral Sounder Level - 90db@10cm
  • Tamper - N/A
  • Material - 316 Grade Stainless Steel
  • Dimensions - 86 x 86 x 2mm - Facia
  • 38mm galvanised back box supplied
  • Surface mount using S0610-38
  • Weight - 0.26kg
  • IP Rating - IP65 front side contact area
  • Approvals - UKCA and CE marked, ROHS compliant

Weather gaskets for the rear of plates, anti tamper screws and stainless steel mock pattress surrounds for surface mounting are available, see related products below.


More Information
Country of Origin UK
Condition New
SKU S1778SY
Associated Product Codes S1778SY
Warranty 3 Years
- Installation Instructions for S1778SY
- Product Information Sheet for S1778SY
