Green overd'r Light & Sounder Custom text Stainless steel

£92.39 Ex Vat
Despatched within 2-3 days
Product code
S1778SGTC

Maximum 45 characters

Green overdoor Light & Sounder Custom text Stainless steel

Stainless Steel flush fitting overdoor light and sounder with 16mm Green Jumbo LED. There are separate terminals provided for the LED. The LED and sounder current limit resistor is provided for 12 vdc operation.
Permanently laser marked with text of your choice. Specify text required when ordering - 45 characters maximum.

Specification
  • Led Current - 50mA @12vdc
  • Switch Contacts - N/A
  • Sounder Current - 40mA @ 12vdc
  • Visual Indication - 1 x Red Jumbo LED
  • Integral Sounder Level - 90dB@10cm
  • Tamper - N/A
  • Material - 316 Stainless Steel
  • Permanently laser marked
  • Ideal for hygienic environments
  • Dimensions - 86mm x 86mm x 2mm - Facia
  • 38mm galvanised back box supplied
  • Surface mount using S0610-38
  • Weight - 0.26kg
  • IP Rating - IP65 front side contact area
  • Approvals - UKCA and CE marked, ROHS compliant

Weather gaskets for the rear of plates, anti tamper screws and stainless steel mock pattress surrounds for surface mounting are available, see related products below.


More Information
Country of Origin UK
Condition New
SKU S1778SGTC
Associated Product Codes S1778SGTC
Warranty 3 Years
- Installation Instructions for S1778SGTC
- Product Information Sheet for S1778SGTC
