Zoneguard Grade 3 Zone Omit EN50131-3:2009 Env. Class II

The Zoneguard ZG800 is a Grade 3 EN50131 zone omit unit that facilitates the secure and safe omission and reinstatement of detection zones in intruder alarm systems, without triggering false alarms. It operates between intruder detection devices and the control panel.

Key Features:
Grade 3 Compatibility - Specifically designed for use with Grade 3 passive infrared detection devices, which must include independent anti-masking and tamper detection.
Uninterrupted Monitoring - The Zoneguard allows 'end of line' resistors for each detection condition to pass through directly to the control panel, this ensures uninterrupted monitoring. The panel can monitor these resistors directly.
Alarm Resistor Flexibility - Zoneguard supports alarm resistors 1kΩ or higher.

Modes of Operation:

• In its simplest form, Zoneguard uses an integrated keyswitch to omit or reinstate up to two detection zones.
• Additional modes are available via the keypad or external devices (e.g., biometric readers, or a combination of keyswitch and keypad), useful when dual responsibility is required.
• Two timed entry/exit modes are also provided.

General Rules for Zone Operation:

• Zones will always be omitted through an omit function.
• If a zone detects an event during reinstatement, it must be returned to the omitted state, the detection condition cleared, and then reinstated.

Specification

• Complies with EN50131 Grade 3
• 12vdc powered
• Designed for detectors with separate alarm, anti-masking and tamper facilities
• Omits two detection zones
• Integral high security keyswitch 30,000+ differs
• Integral 9 digit keypad 500,000 differs
• Dual responsibility or combination mode gives over 150 million differs
• Zone status LEDs
• Fault LED
• Integral piezo sounder
• Output for remote sounder
• Independent zone omitted relay
• Input for remote devices, keyswitches, shunt locks, biometric readers
• Remote re-instate input.
• User programmable code change
• Timed entry/exit modes
• Non-volatile memory
• Local sounder options
• Dimensions 175 x 125 x 60 tapering to 50mm
• Approvals - UKCA and CE marked, ROHS compliant
• Manufactured in the UK
