2 Position keyswitch Red/Green LEDs & sounder 12-24vdc
£42.18
Ex Vat
In stock
Product code
S1709PRG
Two Position keyswitch Red/Green LEDs & sounder
Two position keyswitch mounted on a single gang white ABS plate. Two LEDs are provided, one red and one green, current limited for 12-24vdc operation. The decal is shown labelled O and 1. The keyswitch has DPCO contacts rated at 1A 30vdc. Suitable for maglocks and door strikes.
Specification
- Led Current - 18mA per LED @12-24vdc
- Sounder Current - 20mA @12-24vdc
- Switch Contacts - 1A 30vdc
- Visual Indication - 2 x LEDs one red one green
- Integral Sounder Level - 70dB@10cm
- Tamper - N/A
- Material - White ABS
- Weight - 0.17kg
- IP Rating - IP44 to maintain the IP rating a suitable sealant or gasket for the rear of the plate is required
- Approvals - CE and RoHs compliant
- Back box supplied for surface mount
- 87mm x 87mm x 36mm (Surface mount)
- Can be Semi Flushed onto standard flush back box (Not supplied)
- Mark resistant decal
- Two position keyswitch - removeable in both positions
- Two high brightness LEDs
Anti tamper screws available, see related products below
| Country of Origin | UK |
|---|---|
| Condition | New |
| SKU | S1709PRG |
| Associated Product Codes | S1709PRG |
| Warranty | 3 Years |
| - |  Installation Instructions for S1709PRG |
| - |  Product Information Sheet for S1709PRG |
